JFL-TK8 force measuring sensor load cell

1

Model

JFL-TK8

2

Capacity(KN)

0.5,5,10,20,50,100,200,300,500,600,1000,2000

3

Accuracy

0.05%F.S, 0.1%F.S.

4

Output sensitivity

2.0   MV/V

5

Creep

0.05%F.S/30min

6

Zero-point output

±1%F.S

7

Temperature effect on zero

±0.03%F.S/10℃

8

Temperature effect on output

±0.05%F.S/10℃

9

Working temperature

-10 to +65℃

10

Input resistance

750±10Ω

11

Output resistance

700±5Ω

12

Insulation resistance

＞5000MΩ

13

Safe overload range

150%

14

Excitation voltage

10VDC

15

Material

Good quality alloy steel

16

Wire connection

Power   +(red), power –(black),

signal   + (green), signal –(white)

0.5-5

0.05-0.5

12

90

22

75

25

4xΦ7

10

1

12

100

26

80

30

4xΦ11

20

2

24

125

42

105

42

8xΦ11

50-100

5-10

24

150

48

122

45

8xΦ11

200-300

20-30

30

180

70

142

53

8xΦ13.5

500-600

50-60

36

235

90

190

60

8xΦ17.5

1000

100

36

300

105

236

70

8xΦ22

2000

200

36

350

130

300

90

8xΦ25
